intimus 656144 & 475904 16.86 - P2 16.86 10mm x 70mm, W/BALER 220/60 3PH

The intimus 16.86 SmartShred in its 656144 configuration (paired with item 475904) is a combined shredder and baler with a 10 x 70 mm cross-cut head rated P-2 under DIN 66399. It handles up to 450 sheets of 80 g/m² paper per pass at roughly 550 kg/h and bales the output under 80 kN of force. This is the fastest way to run the 16.86 chassis, intended for overprints, returned catalogs, obsolete stock and other paper with no confidentiality requirement.

16.86 P-2 key points

• 10 x 70 mm particle (700 mm²), rated P-2 / O-2 / T-2 / E-2
• Up to 450 sheets at 80 g/m², approx. 550 kg/h
• Press force 80 kN (9 tons); bales of 60-80 kg (130-175 lb)
• 500 mm (19.7 in) conveyor-fed intake at 1,200 mm working height
• Automatic oiler and SmartShred PLC touchscreen as standard

Built for tonnage, not for secrets

Compared with the 6 x 50 mm build of this frame, the coarse head lifts capacity from 290 to 450 sheets and hourly output from about 480 to about 550 kg. The trade is security. DIN 66399 lets a P-2 particle reach 800 mm², and a 700 mm² strip can leave words legible. Treat this version as a volume reducer for paper that would cause no harm if pieced together, and send anything carrying names, accounts or commercial detail to a finer machine.

Running a shift on the 16.86 P-2

The operator tips material onto the integrated conveyor, which feeds the intake at a comfortable standing height. With the head moving roughly 550 kg an hour and bales weighing 60-80 kg, the press fills quickly, so plan clear space at the discharge end, a pallet or cart for finished bales and spare strapping tape within reach. Bales can be tied twice to hold together in transport, and compaction cuts the waste volume by up to 70%. Auto-reverse clears misfeeds; an emergency stop bar, transparent safety curtain, lockable master switch and dust extractor round out the safety kit.

Supplies the 16.86 P-2 uses

Tape is sold separately in 300 m (item 80804), 400 m (item 80662) and 500 m (item 80661) rolls; the longest roll means fewer stops. The automatic oiler draws on intimus cutting-block oil, item 96946 in a 5-liter container, also bought separately.

16.86 656144 specifications

Comparing the 16.86 P-2 with nearby models

• 16.86 P-3 (6 x 50 mm): identical press, controls and frame; up to 290 sheets a pass but a P-3 particle suitable for internal confidential paper.
• intimus 16.50 P-2 (10 x 70 mm): the same cut size on a conveyor shredder with a bagged 120-gallon chamber and no press.
• intimus 14.87: a smaller shredder-baler with a 6 x 50 mm P-3 head and the same 9-ton press.

Should you buy the P-2 16.86?

Buy it if you process large volumes of non-sensitive paper and want the output baled for a recycler. Pass on it if any of the stream holds personal, financial or client data, since neither 16.86 head reaches P-4, or if the site lacks 220 V three-phase power and the floor capacity for a 2,769 lb machine.
